Long-life DC Electronically Commutated Motor (ECM)
Constant Airflow Profile™ (CAP) airflow monitoring system
BalanceFlow™ plenum provides energy-efficiency and ultra-quiet operation*
Intrinsically-safe negative pressure design
Fully scannable 99.9995+% supply and exhaust ULPA filters. H14 HEPA filters also available.
Aleris OS and 17.8 cm (5") touchscreen information center with:
- Airflow status and all alerts and alarms displayed in intuitive graphics
- Full operational maintenance and certification logs for detailed record keeping
- Status line for alarm conditions and alerts to warn when filter life diminishes to 20% and 10% before alarming at 0%
- UV light timer (on models with UV)
- Password protection for cabinet settings
- 8 Languages
Bright, glare-free LED lighting up to 180 foot-candles (1937 lux). Located outside the contaminated work area
Curved, stainless steel inlet grille with waterfall design and Reserve-Air™ Secondary Airflow Slots
Air-Wave™ Entry System at access opening to enhance containment
Contain-Air™ Negative Pressure Channel at top of sash to enhance containment
Two global universal electrical outlets
- 115V receptacle, maximum amperage draw 5A
- 230V receptacle, maximum amperage draw 3A
10° angled, fully closing sash. 1/4" tempered safety glass with counterbalanced, anti-racking, easy-to-lift mechanism
Unitized, pressure tested stainless steel interior. Optic White epoxy-coated steel exterior
Removable towel catch located under work surface
20.3 cm or 25.4 cm (8” or 10”) working sash height
57 cm (22.5”) max. sash opening & 69 cm (27”) viewing height
Removable, modular type 304 stainless steel, work surface with lift out knobs
Nominal inflow velocity of 105 fpm (0.53 m/sec)
Nominal downflow velocity of 55 fpm (0.28 m/sec)
Approximately 70% air recirculation
Noise level <62 dB (1200 mm [4ft] 20.3 cm [10"] model)
3 m (10’) power cord with plug
Three year warranty

Options

900 mm, 1200 mm, 1500 mm, 1800 mm (3’, 4’, 5’ and 6’) widths
International electrical configurations
Unassembled, epoxy-coated steel, non-welded telescoping base stand with leveling feet
Accessory Package
- UV lamp (254 nm)
- Right and left-side Vacu-Pass™ Cord & Cable Portal
Ventus II Canopy Connection

Required Accessories (Not Included)

Supporting base if non-welded stand option is not selected

Compliance

En 12469 Certified
NSF/ANSI 49 compliant and tested
ISO Class 5 (Grade A) per ISO 14644-1
UL/ETL Standard 61010-1
CE/UKCA Mark (230V models)
